Velo Orange Piolet Frameset Green

Contact us for a build quote!

Piolet by Velo Orange: Your Rugged Bikepacking Companion

Looking to tackle some touring or single day excursions off the beaten path? The Piolet is an adventurous bikepacking and rough-road riding frame in a classically styled frameset with all the modern accoutrement. Designed for off-road touring on dirt and gravel roads, double track, and single track, this rugged frame is built to be sturdy, simple, and highly capable.

Key Features:

• Material: Crafted from 4130 double butted chromoly steel, with a triple-butted fork for reduced weight and extra strength.
• Design: The cool mono-stay wishbone seatstays complement the handsome segmented fork.
• Mounting Options: Covered in bosses for easily mounting racks, water bottles, gear cages, and fenders. Perfect for bikepacking or traditional rack and bag touring.
• Handling: Handles like an XC mountain bike but with a touring twist. Feels natural with drop bars or flat bars. The non-suspension corrected fork offers predictable handling with or without a load.
• Size Specifics: Small uses 26 x 2.4" tires, while Medium, Large, and XL use 29 x 2.4" or 27.5 x 2.8" tires.

Specs:

• Frameset Material: 4130 double butted chromoly steel
• Fork: 1 1/8" threadless, heat-treated triple butted
• Wheel Size: 29" & 27.5+ (M, L, XL), 26" (S)
• Tire: 29" x 2.4" or 27.5 x 2.6" (M, L, XL), 26" x 2.4 (S)
• Rear Spacing: 12x142mm thru-axle
• Front Spacing: 12x100mm thru-axle
• Bottom Bracket: English threaded 73mm, mountain cranksets only
• Brakes: 160 - 180mm disc rotor size, IS mount
• Seatpost: 27.2mm, non-integrated 30.0 mm seat collar (not included)
• Front Derailleur Size: 28.6mm, bottom pull/bottom swing
• Water Bottle Mounts: 3 sets on frame, 2 sets on fork blades
• Fender Bosses: Seatstay bridge, chainstay bridge, under fork crown
• Dropouts: Thru Axle with 2 braze-ons
• Lowrider Thru Bosses: On fork
• Rack Eyelets: 2 sets on seatstays
• Derailleur Hanger: Replaceable stainless steel
• Paint: Metallic Moss

Get ready to tackle any terrain with the Piolet, your rugged and handsome companion for all your bikepacking adventures.
